Body Material
Steel
Color
Black,white
Maximum Load
120KG
Maximum Speed
25KM/H
Range
40KM In Pure Electric Mode
Maximum Climbing Angle
25 Degree
Instrument Display
3-speed Multi-function LCD With Bluetooth
Front Lighting
Include
Tail Light
Include
Front Fender
Include
Rear Fender
Include
Braking Method
Front Disc Brake + Rear Disc Brake
Hub Form
Wire Spoke Wheel
Tire Specifications
Pneumatic Tires
Front Fork
Suspension Fork
Gear
Shimano 7-speed
Rear Shelf
With Non-adjustable Rear Shelf
Length
1780MM
Rear Height
730MM
Front Height
1060MM
Packing Size
1480MM*220MM*765MM
Tire Size
26x2.35 Inches
Net Weight/Gross Weight
27.5KG/33KG
Battery Size
390MM*75MM*105MM
Front Handle Adjustable Height
1060MM-1160MM
Saddle Height
850MM-1100MM
Brake Pad Diameter
160MM

Battery Type
18650Lithium Ion Power Battery
Battery Capacity
14.4Ah
Battery Rated Voltage
36V
Motor Form
Assist Mode
Motor Type
20 Inches / High-speed Gear / Spoke Eheel Brush-less Motor
Motor Rated Power
250W~350W
Motor Rated No-Load Speed
300±10r/Min
Controller
6-MOSFET Controller
Charger Output
42V 2.0A
Charger Input
100~240V 50/60Hz 3.0A
Under Voltage Protection Value
29V±1V
Over Current Protection Value
15A±1A
Charging Time
6.5~7 Hours
Proper Temperature
-10°C-45 °C
Waterproof Level
IP54
